Picklist Mode-Zebra Scanners

Picklist Mode-Zebra Scanners

Picklist mode lets you selectively scan a specific barcode when multiple barcodes are in the scanner's field of view. This is useful for labels that contain multiple barcodes in the same area.

Applies to: Zebra TC20, TC52, TC72, MC3300, MC9300

Enable Picklist Mode

  1. Open DataWedge and select the Default Profile.

  2. Scroll down and select Configure Scanner Settings.

    Configure Scanner Settings option in DataWedgeConfigure Scanner Settings option in DataWedge

  3. Scroll down and select Reader Params.


    Reader Params optionReader Params option

  4. Scroll down and select Picklist.

    Picklist option in Reader ParamsPicklist option in Reader Params

  5. Select Hardware Picklist.

    Hardware Picklist selectionHardware Picklist selection

Using Picklist Mode

  1. Point the scanner toward the label without aiming directly at a barcode.
  2. When the aiming reticle appears, move it over the specific barcode you want to scan.
  3. The device decodes only the barcode under the crosshair, ignoring nearby barcodes.

Aiming reticle targeting a specific barcode on a labelAiming reticle targeting a specific barcode on a label

From Zebra: Pick List Mode allows the user to selectively decode a barcode when more than one barcode is in the device's field of view. Move the aiming crosshair over the required barcode to decode only this barcode. This feature is ideal for picklists containing multiple barcodes and manufacturing or transport labels containing more than one barcode type (either 1D or 2D).
